For the Ultimaker S-line printers, the build volume is the same for single and dual extrusion.

It is not possible to print too close to the switch bay to prevent accidentally adjusting the lift switch. The switch bay is located at the back-right corner and enables nozzle switching. Adjusting the settings as described above will reduce the size of the non-printable areas, but they cannot fully be removed.

#Ultimaker cura easy arrange full

Some hardware parts are within Cura's build volume, preventing the full use of the build volume in the corners. For other printers, such as the Ultimaker 3, this is different. The build volume in Cura is smaller than the glass build plate to ensure that all hardware limitations do not affect the printable area. The images above show the Ultimaker S5 as an example. When all settings are applied as displayed here, the loaded model will be displayed in the same color as the loaded material configuration. When using a brim or large skirt as build plate adhesion, the prime blob can safely be disabled.

If this is within Cura's build volume, this will create a small non-printable area. Before starting a print, the printer will prime by creating a small blob of material on the build plate. The list below shows which print settings affect the build volume and are ordered from most affecting setting to least. Print settings affecting the build volume

Non-printable model. Models on the build plate that are within non-printable areas are automatically turned striped grey-yellow to indicate they do not fit.

Non-printable area. This dark grey area indicates that it cannot be used for printing due to print settings or hardware limitations.

Tip: To adjust these settings, please get familiar with the custom mode first. The non-printable area displayed as a dark-grey area on the build plate will be completely removed when all settings below are adjusted. The default printing profiles provided by our team of print process engineers have built-in safety features that by default do not allow utilizing the maximum build volume by default. Ultimaker 3D printers build volume specifications list the theoretical maximum that can be achieved when using Ultimaker Cura software. Perform the adjustments below at your own risk and consider every change carefully. Note: Ultimaker Cura's integrated and well-tested printing profiles offer maximum reliability and print quality that the platform can offer.
